Power Requirements
The LabelWriter 400 series printers are normally supplied with an external, universal
(100 – 240 VAC) AC power adapter. For OEM applications, a DC voltage can also be
supplied to the main printed circuit board (PCB) of the printer using the JP2 connector.
Note: The printers have been tested and certified for EMC and safety requirements using
the supplied AC adapter. Supplying a non-DYMO power source may change the EMC
and safety certifications.
Input power is variable based on the amount of information printed and the duty cycle of
the label printing. The ratings below are based on normal printer usage, except where
specified.
The printer driver (print commands from the host computer) controls some printing
parameters and will change maximum power usage.
AC Adapter
DYMO part number 93447 (60 W)
Input voltage 100 – 240 VAC, 50/60 Hz, 1.6 Amps
Output voltage 24 VDC, 2.5Amps
PCB Input Power
All LabelWriter 400 series printers have an input voltage of 24 VDC, +/- 5%. Their
power requirements are as follows.
LabelWriter 400 and 400 Turbo Printers
Input current (idle) 0.040 Amps
Input current (typical) 1.75 Amps
Input current (max.) 3.3 Amps based on printing a shipping label (30256) with a
maximum-size filled rectangle, after print head temperature
increases above ambient temperature.
At nominal print head temperature: 2.7 A
In graphics mode: 1.6 A
LabelWriter 400 Series Technical Reference Manual Page 12
