DSP 260

Owner‘s Manual 21

5.9 Edit

Both Factory and User preset can be edited, but edited presets can only be stored in User preset locations.

Standard Edit Mode

The DSP 260 defaults to Standard Edit mode wherein, input and output channel parameters are

appropriately linked. (Refer to “Configurations” illustrations to see which channels are parameter-linked for

each configuration.

Linked parameters are always identical in value. For instance, setting a graphic eq curve for Input A, sets

the same curve for Input B, if the configuration has linked stereo inputs. Either input channel can be edited;

changes will be reflected in both. The same is true for parameters of linked output channels. The only

exception to the linking of parameters is the Mute buttons. Output channels can be individually muted at

any time, either from the DSP 260 front panel or the Graphic User Interface application.

Full Edit Mode

In the Setup menu, the edit mode can be changed to Full Edit. In Full

Edit, no parameter links are enforced, regardless of the

configuration selected. Any parameter can be changed without any

effect on other parameter values.

Regardless of the edit mode selected, there are two means to enter

edit mode: pressing the Edit button or pressing any DSP block button.

Use the < Select > buttons to navigate to the top line of any edit screen, and

the Value Up and Down buttons to navigate to any other Edit screen. As a

short-cut, press a DSP block button to jump to the last selected screen of

said block and navigate as above to reach the desired screen.

5.10 Parameters

The following section is a detailed description of every DSP parameter available in the DSP 260; grouped

by DSP block, in order of the signal flow of the DSP 260.

Input A&B DSP Block

Output 1-6 DSP Block

Not all parameters may be accessible in every preset and, depending on the configurations set by the
