DSP 260
44 Owner‘s Manual
9 Specifications
General
Mains Voltage 100-240 V AC, 50-60 Hz
Power Consumption 25 W
Audio
Analog Inputs 2 x XLR IN, electronically balanced
2 x XLR THRU OUT, electronically balanced
Digital Inputs 1 x XLR AES/EBU IN
Nominal Input Voltage 1.23 V / +4 dBu
Maximum Input Voltage (Without -6dB
Analog Pad Engaged)
8.7 V / +21 dBu
Input Impedance 10 kΩ
Common Mode Rejection -80 dB @ 1 kHz (typical)
A/D Conversion 24-Bit Sigma-Delta
Outputs 6 x XLR OUT, electronically balanced
Nominal Output Voltage 1.23 V / +4 dBu
Maximum Output Voltage 8.7 V / +21 dBu
Output Impedance 50 Ω
D/A Conversion 24-Bit Sigma-Delta
Frequency Response 10 Hz...22 kHz (+/- 0.5 dB)
THD+N < 0.01 % (band limited 22 Hz...22 kHz)
Dynamic Range 111 dB unweighted, band limited 22 Hz...22 kHz
Interfaces
USB USB Type B on front panel (PC Interface)
9-pin DSUB Software Configurable for GPI Preset Recall or Master/
Slave
Signal Processing
Sample Rate 48 kHz
Data Format 24-Bit
Internal Processing 32-Bit Floating Point
Physical
Dimensions (WxHxD) 14 x 14 x 1.75 inces (482.6 x 355.6 x 44.45 mm)
Weight (Net) 10.1 lb (4.6 kg)
Weight (Gross) 13.0 lb (5.9 kg)
