DYNACORD
134
8 Specifications
8.1 Dimensions
Property Value
Mains Voltage 100 to 240 V AC, 50 to 60 Hz
Power Consumption 25 W
Analog Audio Inputs 2 x XLR IN, electronically balanced
2 x XLR THRU OUT, electronically balanced
Digital Audio Inputs 1 x XLR AES/EBU IN
1 x XLR AES/EBU THRU OUT
Digital Audio Format AES3, 32 kHz to 192 kHz sample rate
Nominal Input Voltage 1.55 V / +6 dBu
Maximum Input Voltage (with -6dB PAD engaged) 17.3 V / +27 dBu
Input Impedance 10 k
Common Mode Rejection -85 dB @ 1 kHz (typical)
A/D Conversion 24-Bit Sigma-Delta
Analog Audio Outputs 6 x XLR OUT, electronically balanced
Nominal Output Voltage 1.55 V / +6 dBu
Maximum Output Voltage 8.7 V / +21 dBu
Output Impedance 50
D/A Conversion 24-Bit Sigma-Delta
Frequency Response 20 Hz to 22 kHz (+/-0.5 dB)
THD+N < 0.002 % (band limited 22 Hz to 22 kHz)
Dynamic Range 116 dB (A-weighted)
USB USB Type B on front panel (PC Interface)
Ethernet 2 x RJ-45 ports, 100 MB, Integrated Switch
Control Port 1 x 6-pole Euro block
Software Configurable for Preset Recall
Sample Rate 48 kHz
Data Format 24-Bit
Internal Processing 48-Bit Double Precision
Signal Processing Parametric EQs, 31 band Graphic EQs, Delays, Routing, X-Over, 512 Taps FIR filters, PA limiter, TEMP limiter,
Level, Polarity, Signal generator
Operating Temperature Range 0 °C to 40 °C
Dimensions (WxHxD) 19 x 13.9 x 1.72 inch (483 x 356.1 x 43.6 mm)
Weight (Net) 4.8 kg
