DSP 600
9
ADDITIONAL FEATURES INCLUDE:
2.2 Unpacking & Warranty
Carefully remove the DSP 600 from its packaging and packaging materials. Please save all packing materials and box,
should you ever need to return the DSP 600 for warranty service. Included with the DSP 600 is this Owner’s Manual,
Warranty card, A.C. power cable and a connector (6-pole, for CONTROL PORT). Contact your distributor, dealer or in-
staller if any of these items is not included. Please save the warranty certificate and receipt; which must be presented
at the time of warranty service for the factory warranty to be valid.
2.3 IRIS-Net
The IRIS-Net (Intelligent Remote & Integrated Supervision) PC software is used to configure and operate the DSP 600.
The configuration of the DSP 600 can be done offline (i.e. without connection between the PC and the DSP 600) on the
PC. After the connection between the PC and the DSP 600 has been established via Ethernet or USB, the configuration
can be transmitted to it. In addition to configurations, IRIS-Net can also be used for extensive supervision, control and
monitoring of the DSP 600.
The latest version of IRIS-Net is available at www.dynacord.com.
• Look-ahead Peak limiter with Peak RMS detection
• TEMP Limiter for long-term loudspeaker protection
•Level & Mute
•24-bit, 48kHz D/A converters
• Pilot tone generator
•VU Metering
• Output assignment display LEDs; sub, low, mid & high
•Mute button
•Gain reduction meters
• Electronically balanced XLR inputs and outputs
• XLR thru connectors (analog + AES/EBU)
• -6 dB switchable input level PAD
• Test generator (Sine, pink noise, white noise)
• Contact closure interface
• USB port (front) and Ethernet port (rear) for connection to PC with IRIS-Net software; preset editing and real time parameter control and monitoring.
• Firmware updates via USB port or Ethernet port
• FLASH memory for preset storage and firmware upgrades
• 192 x 32 back-light graphic LCD display
• LCD navigation / editing controls
• DSP block direct access controls
• Auto-ranging internal power supply; 100-240 V AC, 50-60 Hz
• Standard IEC A.C. inlet with external, replaceable fuse
