6 Configurations of the DSP 600
The DSP 600 offers 7 pre-defined configurations. A configuration is a basic setting that includes the routing of inputs
and outputs, the function of the outputs (Sub, Lo, Mid, Hi, Full Range) including basic X-Over filter settings, and different
channel/parameter linking schemes. The active configuration is defined by the selected preset i. e., each preset is based
on a specific configuration which is also displayed next to the preset number and preset name.
Each output employs two X-Over filters that can be assigned to a variety of filter types and slopes. Each output channel
provides 5 additional filters which can be used as parametric EQs, Low- / High-shelving filters, or Lo-Pass and Hi-Pass
filters, and also as All-Pass filters. In addition to a gain control for adjusting the output level and a polarity switch, each
output is monitored by a digital limiter with adjustable threshold, attack and release.
List and detailed description
CAUTION: Please use caution when changing configurations.
HINT: Not all parameters may be accessible in every preset and, depending on the configurations set by the con-
tractor/installer, not all presets and/or preset values may be available for editing. Changes to preset availa-
bility, parameter availability and preset value ranges can only be set using the IRIS-Net application.
• 2 Way Stereo + FR
• 3 Way Stereo
•4 Way + FR
•5 Way + FR
• Free Configuration - Full Edit 2 in 6 Out
• 3 Way Stereo - Mono Sub + FR
• 4 Way Stereo - Mono Sub/LF
