DYNACORD
30
Detail
Use the < SELECT > buttons to navigate to the filter setting (see table below) you wish to adjust, and the Value Up and
Down buttons to alter these settings.
To exit the Input GEQ edit screen, press the Input GEQ button, use the < SELECT > buttons to again highlight the top
line of the edit screen display or press any other DSP block button.
I
NPUT DELAY
The DSP 600 offers an input delay that is useful for compensating for different arrival times of sound origi-
nating from loudspeakers that are closer or further away from the listener than others. A technique known
as the Haas Effect allows the operator to create the illusion that all of the sound has originated from the
stage even though additional speakers have been placed around the room.
HINT: The Input Delay parameter is especially usefull for delay lines. In this case the required delay depends only
on the position of the delay line and is identical for all ways, e.g. output channels of the DSP 600. By editing
t h e I n p u t D e l a y p a r a m e t e r t h e d e l a y s o f a l l o u t p u t c h a n n e l s r o u t e d t o t h i s i n p u t a r e a d j u s t e d a u t o m a t i c a l l y .
Available Input Delay parameters are Delay, Units and Active/Bypass. The Delay parameter allows the user to determine
the Delay time values and the Active/Bypass parameter to activate or deactivate the delay.
To access the Input Delay, press the Delay button found on the input processing menu. Subsequent button presses will
toggle the display between Input A and Input B. Input delay parameters are accessed using the <SELECT> button to
navigate between Delay, Unit and Active/Bypass using the VALUE up/down buttons to adjust values. Following table
shows the available units of the delay.
Fader Description
Fader active (Active)
Fader deactivated (Bypass)
Table 5-8: Fader in GEQ
Parameter Description
Frequency (F) Select frequency band
Gain The amount of boost or cut (-12.0 to +12.0 dB)
Active/Bypass Select Active to activate the filter. Select Bypass to deactivate the filter.
Type
Following filter types are available:
•Symmetric Q
• Proportional Q
•Constant Q
Quality (Q) Quality of the filter
Table 5-9: GEQ band parameters
IN A:GEQ Detail
F:20Hz Gain:0.0dB Active
Type: Symmetric Q
Q: 4.3
IN A:Input Delay Active
Delay: 0.0
Unit: ms
