DSP 600
31
ROUTING
Input selections (In-A, In-B or In-A+B) can be applied to any or all of DSP 600’s six outputs. Choose a desired output
channel from the output menu and press the Edit button to scroll to the Routing window using the Value up/down ar-
rows.
Using the <SELECT> buttons to navigate to the Source parameter, apply a desired input selection to a selected output
channel using the VALUE up/down buttons to choose between inputs (In-A, In-B or In-A+B).
A
RRAY PARAMETRIC EQ
Use the < SELECT > buttons to make the top line of the Edit screen active and the Value Up and Down buttons
to navigate to the Array Eq screen. In the ARRAY CONTROL section an 5-band parametric equalizer is available
for each output.
Use the < SELECT > buttons to navigate to the filter setting (see table below) you wish to adjust, and the Value Up and
Down buttons to alter these settings. Press the Value Up and Down buttons once to increment values by one unit, or
press and hold to scroll rapidly through available values.
A
RRAY DELAY
Use the < SELECT > buttons to make the top line of the Edit screen active and the Value Up and Down buttons to navigate
to the Array Delay screen. In the ARRAY CONTROL section a delay is available for each output.
HINT: The Array Delay parameter can be used for adjusting the individual cabinets within a loudspeaker cluster,
such as a subwoofer array or a center loudspeaker cluster. For example, in a speaker cluster consisting of
two horn-loaded loudspeakers, it is helpful to apply 3-5 mS of delay to one of the loudspeakers in the cluster
to improve the coverage in the overlap of the horn patterns. Additionally, the array delay provides a conve-
nient section to apply dedicated delay to individual subwoofer cabinets to create gradient or beam-formed
arrays.
Unit Description
sec seconds
ms milliseconds
μs microseconds
samples samples
feet feet
inch inch
meter meters
cm centimeters
Table 5-10: Input Delay units
Type Frequency Slope / Order Resp / Q Ga i n
Loshelv
20 to 20000 Hz
6dB/oct.
12dB/oct.
-
-18.0 to +12.0 dB
Hishelv
6dB/oct.
12dB/oct.
-
PEQ - 0.40 to 40
Lopass
6dB/oct.
12dB/oct.
-
0.4 to 2.0
-
Hipass -
Allpass
1
2
-
0.4 to 2.0
-
Table 5-11: Array Control EQ
OUT 1:Routing
Source: In B
OUT 1:Array PEQ1 Active
Type: PEQ F:30.0Hz
Q: 0.7 Gain: 1.0dB
