DYNACORD
32
Use the < SELECT > buttons to navigate to the delay setting you wish to adjust, and the Value Up and Down buttons to
alter these settings.
O
UTPUT PARAMETRIC EQ (PEQ)
Pressing the PEQ button places the current preset in Edit mode and jumps the LCD screen to a pre-selected
parametric EQ (bands 1-6). Subsequent button presses advances the display to the next output channel (OUT
1 to OUT 6). Use the <SELECT > buttons to navigate between the PARA EQ BAND (1-6), Type, Frequency, Q
and Gain parameters. Adjust the values of each parameter using the up/down VALUE arrows.
O
UTPUT X-OVER
The DSP 600’s crossover is an advanced frequency division process that is accomplished by applying a va-
riety of high-pass and low-pass filters to a predetermined set of crossover points. Speaker systems are gen-
erally made up of several drivers that are dedicated to a specific range of frequencies that result in the
efficient reproduction of the audio spectrum and a smooth sound. The DSP 600 crossover routes frequen-
cies to the appropriate drivers to accurately reproduce sound. The crossover network can also be used to
insure that low-frequency energy is not accidently routed to the mid-range or tweeter drivers that may result
in potential damage. Available DSP 600 crossover parameters are Type and Frequency.
To access the Crossover screen, press the X-Over button. Subsequent button presses will toggle the display
between OUT 1 to OUT 6. Use the Value Up and Down buttons to navigate between the X-Over Hipass, X-Over
Lopass, X-Over Delay and FIR Filter screens.
The DSP 600 Crossover offers a variety of Hipass and Lopass filters depending on the configuration output selected
along with a variety of selectable filters and frequency ranges that are adjustable using the up/down VALUE arrows.
Filter type Frequency Slope / Order Resp / Q Ga i n
Loshelv
20 to 20000 Hz
6dB/oct.
12dB/oct.
-
-12.0 to +18.0 dB
Hishelv
6dB/oct.
12dB/oct.
-
PEQ - 0.40 to 40
Lopass
6dB/oct.
12dB/oct.
-
0.4 to 2.0
-
Hipass -
Allpass
1
2
-
0.4 to 2.0
-
Table 5-12: Parametric EQ
Parameter Description
Type Type offers list of selectable slopes/response Q‘s
•Thru
•6dB
12dB, Q = 0.5 to 2.0
Bessel: 12 dB, 18 dB or 24 dB
Butterworth: 12dB, 18dB or 24 dB
Linkwitz-Riley: 12dB or 24 dB
Frequency Frequency offers a selectable frequency range from 20 to 20000 Hz.
Trim The amount of boost or cut
Table 5-13: Crossover parameters
OUT 1:Array Delay Active
Delay: 7.0
Unit: ms
OUT 1:PEQ1 Active
Type: PEQ F:30.0Hz
Q: 0.7 Gain: 1.0dB
OUT 1:X-Over Hipass
Type:12dB Butterworth F:80.0Hz
Trim:3.0dB
