OPERATING MANUAL
Signal Generator specifications
Weight
14.5 kgs (32lbs)
Size
33 x 26 x 23cm (13 x 10 x 9”)
Construction
Aluminium drawn case with hinged storage lid
Sealing
(Protection
Class)
IP66 (closed) / IP65 (open)
Rechargeable
batteries
3 x 12v – 7Ahr sealed lead/acid
External
power
11.5 to 18v DC
Maximum
output
750mA (RMS) AC coupled at 937.5Hz on internal
batteries
1000mA (RMS) AC coupled at 937.5 Hz with external
power
Survey time
on
(on internal
batteries)
(on external
power)
8 hrs at 600mA
Indefinite depending on capacity of power source
Operating
temperature
range
-20 to +40oC (-4 to +104oF)
NOTE: battery capacity reduces at low temperatures
Connectors
•
2 x shrouded 4mm output sockets
•
1 x multi-pole charger and external power socket
