OPERATING MANUAL
PART 1 – OPERATION
AVW 150203 – 2010O&MPt1-Sec2.DOC
Section 2 OVERVIEW
2.1. Introduction
This section described the C-Scan Pipeline Survey System model 2010: what the
system comprises, how to unpack it, set it up and get it started. A detailed contents list
for this section appears below.
Contents
2.1 Introduction 2 – 1
2.2 Unpacking and activating the C-Scan 2010 Detector Unit 2 – 2
2.2.1 Unpacking
2 – 2
2.2.2 Charging the Signal Generator (SG)
2 – 2
2.2.3 Charging the Detector Unit (DU)
2 – 3
General Guidance Notes on the batteries used in the C-Scan system
2 – 7
2.3 Getting Started 2 – 8
2.3.1 The display screen and keypad
2 – 8
2.3.2 Quick Start
2 – 12
2.3.2.1 Start-up screen
2 – 12
2.3.2.2 Pipeline Specification screen
2 – 13
2.3.2.3 Pipeline Specification Confirmation screen
2 – 13
2.3.2.4 Start-up screen (GPS ON)
2 – 13
2.3.3 Search
2 – 14
2.3.4 Calculate
2 – 16
2.3.5 Store Data
2 – 16
2.3.6 Entering Distance
2 – 17
2.3.7 Graphs
2 – 19
The C-SCAN 2010 is the next generation design in the 2000 series Pipeline Survey
System. The system increases the speed and accuracy over previous models, with
more statistical features for noise reduction.
Improvements over the previous model include the following features:
• Built in GPS unit for accurate position indication.
• Attenuations can be calculated using GPS position information
• Full graphic interface allows the display of data without the use of a laptop or PC.
