SAFETY DECALS, LOCATION/DESCRIPTION
Crush zone, articulation/
Drum. Maintain a safe dis-
tance from the crush zone.
Warning - hot surfaces in
the engine compartment.
Do not touch.
Warning - rotating engine
components. Keep your
hands at a safe distance from
the danger zone.
The operator is urgently
requested to read the safety
manual, and the operation
and maintenance instructions
before using the machine.
1.
2.
3.
6.
903424
903459
903423
903422
The articulation must be
interlocked when lifting.
Read the instruction manual.
7.
Lifting point
Diesel fuel
Tire pressure
110 kPa
16 psi
12.
11.
357587
991658
991990
908229
17.
8.
904165
Toxic gas. Read the instruc-
tion manual.
Hydraulic
fluid
Biological
hydraulic
fluid
272372 904601
13.
Alt. 1 Alt. 2
Battery
disconnector
16.
904835
Securing
point
14.
382751
10.
15.
Handbook
compartment
903425
Tires filled with ballast.
Read the instruction manual.
4.
Mass Kg
904870
9.
Lifting plate
Emergency exit
5.
903985
