19Xeo 4 / Xeo 6
Select a Hub One of the three LEDs is blinking. LED 1 = Hub A
LED 2 = Hub B
LED 3 = Hub C
Select an input One of the four LEDs is blinking. LED 1 = INPUT 1
LED 2 = INPUT 2
LED 3 = INPUT 3
LED 4 = INPUT 4
Hub search The blue LED is blinking; the lights in
the white LEDs move back and forth.
Searching for an active input on the Hub
Synchronization The red LED is blinking; the lights in the
white LEDs move back and forth.
System synchronization
Volume, mute A number of white LEDs are illuminated. The number of LEDs indicates the selected volume.
The rst LED is blinking. The speaker is muted.
