Dyson DC24 Service Manual

Fitting notes
Service manual
23 Ensure when fitting the swivel lock
into the side of the yoke assembly
that the spring locates onto the
side of the peg.
25 Once initially released it can then
be removed by easing it away
from the yoke assembly.
24 If necessary the connector clip can
be removed by initially inserting a
screwdriver into the gap.
13

Dyson DC24 Specifications

General

Type	Upright
Weight	5.4 kg
Cleaner Head	Motorized brush bar
Cyclone Technology	Root Cyclone™ technology
Color	Yellow
Dust Capacity	0.34 L
Special Features	Ball technology
Filter	Lifetime washable filter
