E Instruments E4500-S User Manual

12
K000000000EJ 023826A0 100714
4.3 Overview of Flue Gas Analyzer Components
A
AA
A
B
BB
B
C
CC
C
P
PP
P
O
OO
O
Q
QQ
Q
Q
QQ
Q Q
QQ
Q
E
EE
E
D
DD
D
G
GG
G
L
LL
L M
MM
M
I
II
I
F
FF
F
N
NN
N
H
HH
H
LEGEND
A
AA
A
Keypad
B
BB
B
Display
C
CC
C
Access Cover to the printer paper roll
D
DD
D
B-type USB connector to connect the device to
the power source or to a PC
E
EE
E
Serial cable connector for connection with
accessory probes
F
FF
F
T2 - Tc-K female connector to connect
combustion air temperature probe
G
GG
G
T1 - Tc-K female connector to connect gas probe
H
HH
H
Gas Exhaust / Exit
I
II
I
AUX connector (input for optional external probes)
L
LL
L
P- connector (negative input to measure draft)
N
NN
N
P+ connector (positive input to measure
differential pressure)
O
OO
O
Battery compartment access cover
M
MM
M
IN connector (gas exhaust probe input by means
of a complete condensate separator unit)
Q
QQ
Q
Magnets
P
PP
P
Sensor compartment access cover
