Proteus 1000 Operation Manual 99
Edit Menu
Defining Layer Parameters
Volume Envelope An envelope can be described as a “contour” which is used to shape the
sound over time. The Volume Envelope controls the volume of the sound in
the current layer over time. The way the volume of a sound evolves has a
profound effect on how we perceive the sound.
Each instrument has its own Factory preset Volume Envelope setting. The
Volume Envelope allows you to program your own envelope settings.
Selecting the Mode
The Mode field determines whether the layer will use the instrument’s
default envelope (Factory) or use the user-programmed Volume Envelope.
There are three mode options and repeat.
OO
OO
Factory Mode is useful
for Instruments containing
multiple drums, since each drum
can have its own envelope
settings.
• Factory: Uses the factory preset envelope contained in each instrument.
If you select the “Factory” mode, the Volume Envelope parameters are
disabled and the factory defined settings are used instead.
__
__
If two adjacent segments
have the same level in a “time-
based” envelope, the segment
will be skipped. Adjacent
segments must have different
levels for the rate control to work.
• Time-based: Defines the Volume Envelope rates from 0 to 127 (approxi-
mately 1 ms to 160 seconds). The Master clock has no affect on time-
based rates.
• Tempo-based: The Volume Envelope times vary based on the Base
Tempo setting. Note values are displayed instead of a number when the
time corresponds to an exact note value. Tempo-based envelopes are
useful when using external sequencers and arpeggiators because the
envelope rates compress and expand according to the Base Tempo set-
ting, keeping the envelopes in sync with the sequence or arpeggio.
See “Base Tempo” on
page 52.
Tempo-based envelope rates change according to the Base Tempo rate.
L1
VOLUME ENVELOPE
Mode: factory
= Initial Setting
= Increase Master Tempo
= Decrease Master Tempo
Tempo-Based Envelopes
