38 E-MU Systems
Master Menu
Defining Master Parameters
The Sends function as effect processor inputs (effect sends). The four Effect
Sends allow you to get the most out of the two effect processors. For
example, with Effect B set to an echo algorithm, you could route one MIDI
channel to Send 3 and set the effect amount to 80%. Another MIDI channel
could be routed to Send 4 with an effect amount of only 5%. This is almost
like having two different effects!
channel 16: use preset
MIX OUTPUT
channel 15: Send 1
MIX OUTPUT
S
E
N
D
1
M
A
I
N
OUTPUT SECTION
& EFFECTS PROCESSORS
MIDI Channel 1
MIDI Channel 2
MIDI Channel 3
MIDI Channel 4
MIDI Channel 5
MIDI Channel 6
MIDI Channel 16
MIDI CHANNEL
Hall 1
Effect
A
Chorus
Effect
B
B➟A
Preset
Preset
FX Sends
Send 2 10%
Send 3 0%
Send 4 0%
Send 1 15%
FX Sends
Send 1 0%
Send 4 15%
Send 3 20%
Send 2 0%
S
E
N
D
3
S
E
N
D
4
S
E
N
D
2
