Proteus 1000 Operation Manual 161
Save/Copy Menu
Sound Authoring
Rename Flash SIMM This utility allows you to rename the Flash SIMM and change its ID
number. Flash SIMMs can have any five letter name you choose. Each Flash
SIMM in a Proteus 1000 unit must have a unique ID number (106-119).
The field in the upper right corner selects between multiple Flash SIMMs. If
only one Flash SIMM is installed, the field cannot be modified.
The Flash ID is the MSB
of the MIDI Bank Select
command used to select the
Sound Bank.
1. Make sure a Flash SIMM is inserted in a Proteus 1000 SIMM socket.
__
__
If there is no Flash SIMM
in the unit, the error message,
“Requires Flash SIMM” will be
displayed.
2. Press the Save/Copy menu button.
3. Rotate the Data Entry Control to select the “Rename Flash SIMM”
function shown above.
4. Move the cursor to the “New Name” field and rename the SIMM using
the Data Entry Control to select the letter and the cursor keys to select
the position.
5. Set the Sound ID number for the SIMM. It doesn’t matter which
number you choose as long as the same number isn’t used in another
SIMM.
6. Press Enter. The following screen appears and the Enter LED will be
flashing.
7. Press Enter again to confirm or any other button to abort. The
following screen appears:
8. The Flash presets cannot be used until Proteus 1000 is rebooted (power
off then on). Reboot the Proteus 1000 and verify that the new Flash
bank has been properly renamed.
RENAME FLASH SIMM Flash
New Name: Drums ID: 110
Press ENTER to Update
Flash SIMM data
CHANGING SIMM NAME & ID
(takes about 2 minutes)
