“BT” Buon triggers.
P.I.R.A.C. auto-close mode.
Basic operang
features
The BT funcons are the primary full gate opening funcons for motor vehicle access.
There are two ways of acvang the “BT” funcons on this control card. Either via the hardwired BT input or the BT receiver channel.
In P.I.R.A.C. auto-close mode, all BT triggers are treated as per simple auto-close. The dierence in this mode is how the system responds to the safety
beam triggers while the gate is opening. Below is an example of P.I.R.A.C. auto-close mode when the safety beam circuit is triggered while the gate
is in operaon.
In this mode mode the following advanced features are available: - Holiday lock-out and Party mode.
NB! For any auto-close feature to work, a pair of safety infra-red beams must be installed and funconing correctly. If no safety infra-red beams are
installed then the gates will open but not close again.
Acon Response
Momentary BT trigger.
Gate begins
opening.
No buzzer tones.
Safety beam circuit
triggered while gate is
opening.
The gate
connues
opening.
No buzzer tone.
Safety beam circuit
cleared while gate is
opening.
Gate stops and
immediately
starts closing
again.
No buzzer tones.
Safety beam circuit
triggered while gate is
closing.
Gate stops and
immediately
starts opening
again.
No buzzer tones.
Gate reaches open
posion while safety
beam circuit is sll
triggered.
Gate remains
open waing
for safety beam
circuit to be
cleared.
No buzzer tones.
Safety beam circuit
cleared while gate is in
the open posion.
Auto-close
mer starts
counng down.
No buzzer tones.
Auto-close mer mes
out. Safety beam circuit
not triggered.
Gate begins
closing.
No buzzer tones.
At full closed posion. Gate stops. No buzzer tones.
0
0 sec.c.
0
20 sec.
Gate closed.
