E.T. Systems Drive 600 - Receiver Relay Mode; Latch Mode; One Shot Pulse Mode

18
ON
Com N/O
N/C
OFF
Com N/O
N/C
ON
Com N/O
N/C
OFF
Com N/O
N/C
Basic operang
features
Auxiliary relay modes.
Receiver relay mode.
With receiver relay mode selected, the auxiliary relay will operate in exactly the same way as a single channel receiver would, whenever a transmier
buon programmed into the “Relay” receiver funcon is pressed and released.
Latch mode.
The transmier must be released and pressed again to reacvate the relay each me.
Acon Response
Momentary relay trigger.
Auxiliary relay
switches on.
No buzzer tones.
Momentary relay trigger.
Auxiliary relay
switches o.
No buzzer tones.
One shot pulse mode.
The transmier must be released and pressed again to reacvate the relay each me.
Acon Response
Momentary relay trigger.
Auxiliary relay
switches on.
No buzzer tones.
Relay mer mes out.
Auxiliary relay
switches o.
No buzzer tones.
0
0 sec.c.
