Auxiliary relay modes.
Strike lock mode.
Basic operang
features
With Strike lock mode selected, the auxiliary relay will pulse for the preprogrammed on me, half a second before the gate opens.
Whenever a lock is installed with the system, a separate baery backed up power supply matching the lock load must be installed. Failure to do this
can damage the charger and baery of the control unit.
Below is an example of strike lock mode when standard BT mode is acve.
Acon Response
Momentary BT trigger.
Auxiliary relay
acvates.
No buzzer tone.
Half a second aer
the auxiliary relay has
acvated.
Gate begins
opening.
No buzzer tone.
Aer the
preprogrammed relay
on me.
Auxiliary relay
deacvates and
gate connues
opening.
No buzzer tone.
Gate reaches open
posion.
Gate stops. No buzzer tone.
Momentary BT trigger.
Gate begins
closing.
No buzzer tone.
At full closed posion. Gate stops. No buzzer tone.
ON
Com N/O
N/C
OFF
Com N/O
N/C
0
0.5 sec.
0
1 sec.
Gate closed.
