E.T. Systems Drive 600 - “PED” Pedestrian Trigger

12
Basic operang
features
“PED” Pedestrian trigger.
(With no safety beams installed)
The PED trigger is a higher security opon and is used when access to or from the property is limited to exclude motor vehicles.
In the case of no safety beams being installed then the pedestrian auto-close funconality is disallowed for safety.
If the Loop or the BT triggers are acvated at any me during the pedestrian roune, the gate will open to the full open posion and the pedestrian
transacon is cancelled. The system then reverts to either the Loop or BT trigger mode depending on which was triggered.
There are two ways of acvang the “PED” funcons on this control card. Either via the hardwired PED input or the PED receiver channel.
Acon Response
Momentary PED trigger.
Buzzer beeps
pre-run
warning.
Aer buzzer silences.
Gate begins
opening.
No buzzer tones.
At previously
programmed
pedestrian opening
distance.
Gate stops
and waits for
a pedestrian
trigger to close.
No buzzer tones.
Momentary PED trigger.
Buzzer beeps
pre-run
warning.
Aer buzzer silences.
Gate begins
closing.
No buzzer tones.
At full closed posion. Gate stops. No buzzer tones.
x3
x3
STOPSTOP
STOP
Gate closed.
