E.T. Systems Drive 600 - Page 13

13
“PED” Pedestrian trigger.
(With safety beams installed)
Basic operang
features
The PED trigger is a higher security opon and is used when access to or from the property is limited to exclude motor vehicles.
If the safety beams are triggered while the gate is closing in pedestrian mode, the gate will only return to the preprogrammed pedestrian open
posion.
If the Loop or the BT triggers are acvated at any me during the pedestrian roune, the gate will open to the full open posion and the pedestrian
transacon is cancelled. The system then reverts to either the Loop or BT trigger mode depending on which was triggered.
There are two ways of acvang the “PED” funcons on this control card. Either via the hardwired PED input or the PED receiver channel.
Acon Response
Momentary PED trigger.
Buzzer beeps
pre-run
warning.
Aer buzzer silences.
Gate begins
opening.
No buzzer tones.
At previously
programmed
pedestrian opening
distance.
Gate stops and
the pedestrian
auto-close
mer starts
counng down.
No buzzer tones.
Momentary PED trigger
or safety beam circuit
trigger.
Pedestrian
auto-close
mer resets.
No buzzer tones.
Pedestrian auto-close
mer mes out.
Buzzer beeps
pre-run
warning.
Aer buzzer silences.
Gate begins
closing.
No buzzer tones.
At full closed posion. Gate stops. No buzzer tones.
x3
STOP
5 sec.
0
STOP
5 sec.
0
STOP
0
0 sec.c.
x3
STOP
Gate closed.
