Basic operang features.
Collision sensing and safety overload rounes.
In the case of the gate colliding with an obstrucon such as a person passing through the entrance way, the collision sensing will automacally detect
the collision and the system will run a safety overload roune.
Safety overload roune while gate is opening.
Acon Response
Gate collides with a
pedestrian for example.
Gate stops
opening.
Once gate has stopped.
Gate reverses
momentarily
to release
pressure.
No buzzer tones.
Aer reversing
momentarily.
Gate stops and
waits for next
trigger to close.
No buzzer tones.
Safety overload roune while gate is closing.
Acon Response
Gate collides with a
pedestrian for example.
Gate stops
closing.
Once gate has stopped.
Gate reverses
back to the full
open posion.
No buzzer tone.
Aer reversing to the
full open posion.
Gate remains
in the full open
posion unl
the next trigger
to close.
No buzzer tone.
x1
STOP
STOP
STOP
x1
STOP
STOP
