E-XTEQ DS ONE User Manual / Ref. MAN_DSOne_STL_EN_V1.3
Other diagnostics 1/2
OTHER DIAGNOSTICS ////////
Some diagnostics are locked because they are only used in certain authorised
departments. Refer to the “Other settings” section of this manual to unlock the other
diagnostics. These are the COMPOUND, PLANT and MBM diagnostics.
Once the diagnostics modes are
unlocked, return to the main screen
and click on the diagnostic icon.
Additional diagnostics will appear.
The COMPOUND and PLANT
diagnostics are performed in the same
way as the PDI and REPAIR diagnostics
(see the PDI and REPAIR diagnostic
section of this manual).
MBM (multi battery mode) diagnostics
are used to test batteries of identical
characteristics in succession. Click on
the MBM icon to perform a diagnostic.
Select the battery chemistry. Select the battery standard.
Select the battery value using the
arrows. Press the
button to
validate.
The characteristics of the battery will be
displayed. If the battery characteristics
are not correct, click on
to change
them.
