Installation, Operation and Parts Manual
EE-6435B .WF
Step 11: Leveling
Attention: No vehicle on platforms when leveling.
Firstly, level the platforms when mechanical safety locks are disengaged.
Switch on and press the UP button when the green power indicating light is on. When the steel cable has been tightened, measure if the two
platforms are of the same height from the ground with a leveling pipe. If not, adjust screw② fixed on top of the power side post.
Secondly, level the platforms after mechanical safety locks are engaged.
Raise the platform about 750mm-800mm high and check if the safety blocks in the four posts could be engage synchronously. If not, adjust
screw ①to ensure the synchronization.
