Installation, Operation and Parts Manual
EE-6435B .WF
43
Pos.
CODE
Name
QTY
NOTE
11
208106001
Straight pressed oil cup
2
12
202109060
Hex socket button head screw M12*145
4
GB/T 70
13
615027005
5T oil cylinder
1
14
614027033B
Steel rope connection block
1
15
208010001
Steel rope clip
4
16
Open slotted nut
1
17
Cotter pin
1
18
410270231
5T oil cylinder shaft
1
19
202206002
Hex socket locking screw
1
GB/T 78
20
410290393
Oil cylinder guiding plate
1
21
420270240
Guiding slider
2
22
202110005
Hex socket button head screw M8*20
3
23
202111007
Hex socket flat head screw M 8*20
2
24
202111028
Hex socket flat head screw M12*80
8
25
410274513
Front wheel retaining plate
2
26
201102027
Hex head full swivel screw M12*30
4
27
410277313
Limit rod
2
57L
27
410277063
Limit rod
2
48L/52L
28
202111005
Hex socket flat head screw M8*15
12
29
614027279
Portable box I--380
2
48L/52L/57L
30
614027280
Portable box II-200
2
57L
31
614027281
Portable box III-90
4
48L/52L/57L
32
615027049
Turntable
2
Optional
33
410276373
Cover plate
2
34
202110003
Hex socket button head screw M6*12
8
35
614027581
6435BWF.57L slip plate
2
57L
35
614027582
6435BWF.52L slip plate
2
52L
35
614027583
6435BWF.48L slip plate
2
48L
36
410250221B
Bolt
4
37
420210030
Nylon sheath
4
38
410250011
Washer
4
39
206201007
Cotter pin
4
40
420270100C
Ball holder
6
41
420270110
Ball
240
42
410274470
Pull spring
24
43
202109020
Hex socket cylinder head screw M8*15
24
44
203101004
Hex nut M6
24
45
Auxiliary lifting platform (secondary)
1
46
Auxiliary lifting platform (main)
1
