EasyIO FW Series User Manual

EasyIO FW Series – User Reference v3.0
16
Digital Output Wiring Connection
EasyIO FW Series digital output is for general purpose isolated digital output connections (relay output).
Pilot Duty rating is as below (Pilot Duty);
 24 VAC , 2.0A 
 24 VDC , 2.0A 
Digital Output
2 Channels – FW-14 only
Type
Relay Contacts, SPST NO, 48VA at 24VAC,
It does not output voltage or current. It is a dry relay contact.
Digital Output Connection
