EasyIO FW Series User Manual

EasyIO FW Series – User Reference v3.0
6
Introduction
EasyIO FW Series is the most powerful wireless Sedona controller in the market. It is equipped with two
32-bit Processors, the first in the Automation industry, with a 580MHz MTK processor and an ARM M0
Cortex for the I/O management and A-D processing, and also with a Linux 3.18 OS for premium
performance. Supports BACnet as server and TCom or premium performance with Niagara AX and N4.
 The Build in boot loader can be carried out remotely. No more manual service button
needed is used. 
 Firmware upgrading can be done remotely and without any assistant. 
 Firmware upgrading is via ftp client. 
This document describe about basic connection and technical specifications.
It applies for EasyIO FW Series family.
FW
Model
UI
AO
DO
Pressure
Sensor
Ethernet
EIA-485
Protocol Supported
FW-14
8
4 (Voltage only)
2
-
2
1
Sedona
BACnet IP and MSTP Client
BACnet IP server
FW-08
4
4 (Voltage only)
-
-
2
1
Sedona
BACnet IP and MSTP Client
BACnet IP server
FW-08V
4
4 (Voltage only)
-
1
2
1
Sedona
BACnet IP and MSTP Client
BACnet IP server
Table shown above show the IO configuration
