EFX48-xx Series with RM3-340/440 Installation and Operation Guide
142
Copyright © 2019 Eaton Corporation. All Rights Reserved.
IPN March 2019
Load Current Measurement
Number of Load Current Measurements 6
Range 0 to +30A
Resolution <10mA
Accuracy ±1% / ±100mA (whichever is greater)
over temperature range 0 – 40°C
Bus Voltage Measurement
Range -40 to -59V
Resolution <10mA
Accuracy ±0.25% over temperature range 0 – 40°C
String Voltage Measurement
Number of String Voltage Measurements 2
Range -30V to -59V
Resolution <10mV
Accuracy ±1% over temperature range 0 – 40°C
Communications
Ethernet Interface:
Connector:
Protocols:
10/100baseT
RJ45
TCP/IP, SNMP, http (Web),
https (secure Web),
Web browser:
See compatible versions on page
49.
Cable: CAT5E
