Eaton EFX48 e-Fuse Series User Manual

Specifications
Copyright © 2019 Eaton Corporation. All Rights Reserved.
IPN March 2019
143
Load Parameters
Availability
name
MMI reference MIB reference
Parameter
description
Factory
Default*
min max Step size
SNMP MMI
WEBPAGE
Load 1
MMI LED loadConnectionState
Connection off off on n/a
  
Rating loadCurrentRating
Rating (A) 10.0 5.0 25.0 1.0
  
Priority loadOutputPriority
Priority Priority Non-
priority
Priority n/a
  
Auto retry loadRestartEnable
Restart enable yes no yes n/a
  
Load 2
MMI LED loadConnectionState
Connection off off on n/a
  
Rating loadCurrentRating
Rating (A) 10.0 5.0 25.0 1.0
  
Priority loadOutputPriority
Priority Priority Non-
priority
Priority n/a
  
Auto retry loadRestartEnable
Restart enable yes no yes n/a
  
Load 3
MMI LED loadConnectionState
Connection off off on n/a
  
Rating loadCurrentRating
Rating (A) 10.0 5.0 25.0 1.0
  
Priority loadOutputPriority
Priority Priority Non-
priority
Priority n/a
  
Auto retry loadRestartEnable
Restart enable yes no yes n/a
  
Load 4
MMI LED loadConnectionState
Connection off off on n/a
  
Rating loadCurrentRating
Rating (A) 10.0 5.0 25.0 1.0
  
Priority loadOutputPriority
Priority Priority Non-
priority
Priority n/a
  
Auto retry loadRestartEnable
Restart enable yes no yes n/a
  
Load 5
MMI LED loadConnectionState
Connection off off on n/a
  
Rating loadCurrentRating
Rating (A) 10.0 5.0 25.0 1.0
  
Priority loadOutputPriority
Priority Priority Non-
priority
Priority n/a
  
Auto retry loadRestartEnable
Restart enable yes no yes n/a
  
Load 6
MMI LED loadConnectionState
Connection off off on n/a
  
Rating loadCurrentRating
Rating (A) 10.0 5.0 25.0 1.0
  
Priority loadOutputPriority
Priority Priority Non-
priority
Priority n/a
  
Auto retry loadRestartEnable
Restart enable no no yes n/a
  
Settings
Disconnect loadDisconnectLevel
Disconnnect (V) 45.0 36.0 59.9 0.1
  
Reconnect loadReconnectLevel
Reconnnect (V) 47.0 36.1 60.0 0.1
  
Recog time loadConnectionDelay
Delay (s) 10 10 600 10
  
No AC enable loadMainsFailEnable
Mains fail
enable
No no yes n/a
  
No AC delay loadMainsFailDelay
Delay (min) 60 0 600 10
  
Restart del loadRestartDelay
Delay (min) 1 1 120 1
  
Restart lim loadRestartLimit
Limit 10 1 100 1
  
* Factory defaults may not be correct for your installation. You need to set-up your own configuration file to over-write the factory
defaults after a factory reset if necessary.
