Eaton EFX48 e-Fuse Series - Front Views

EFX48-xx Series with RM3-340/440 Installation and Operation Guide
46
Copyright © 2019 Eaton Corporation. All Rights Reserved.
IPN March 2019
Front Views
RM3-400 Models

Rectifier modules (see details on page 47). Up to
3 in RM3-400 models, 1 or 2 in RM3-410/420
models.

Rectifier blank panel RM3B-A01 (for un-used
rectifier positions) – not shown

DU-X e-Fuse module (see details on page 47)


