Eaton EFX48 e-Fuse Series User Manual

EFX48-xx Series with RM3-340/440 Installation and Operation Guide
144
Copyright © 2019 Eaton Corporation. All Rights Reserved.
IPN March 2019
Strings
SNMP
MMI
WEBPAGE
name
MMI reference MIB reference
Parameter
description
Factory
Default*
min max
Step
size
String
1
LED on front panel stringConnectionState
Connection off off on n/a
  
Rating stringCurrentRating
Rating (A) 25 25 50 1
  
String
2
LED on front panel stringConnectionState
Connection off off on n/a
  
Rating stringCurrentRating
Rating (A) 25 25 50 1
  
Trip reconn
Enable stringReconnectEnable
Restart enable no no yes n/a
  
Interval stringReconnectDelay
Delay (s) 60 60 900 5
  
Attempts stringReconnectLimit
Limit 5 1 10 1
  
Temp comp
Enable batteryCompensationEnable
Enable Yes no yes n/a
  
Reference batteryCompensationReference
Ref (degC) 20 0 50 1
  
Low limit batteryCompensationLowLimit
L limit (degC) 0 -40 20 1
  
High limit batteryCompensationHighLimit
H limit (degC) 50 0 60 1
  
Slope batteryCompensationSlope
Slope
(mV/degC)
-4.00 -10.00 0 0.1
  
Battery LVD
Disconnect batteryDisconnectLevel Disconnnect(V
)
40.0 36.0 60.0 0.1
  
Reconnect batteryReconnectLevel
Reconnnect(V) 42.0 36.0 60.0 0.1
  
Recog time batteryConnectionDelay
Delay (s) 10 10 600 5
  
No AC enable batteryMainsFailEnable
Mains fail
enable
no no yes n/a
  
No AC delay batteryMainsFailDelay
Delay (s) 30 10 360 1
  
Capacity
Capacity batteryTotalCapacity
C10 (Ahr) 100 10 400 10
  
BC
L
BCL batteryChargeRateLimit
Rate limit
(%C)
10 1 100 1
  
Charg
e state
Threshold batteryChargeStateThreshold
Threshold (A) 3 2 20 0.1
  
Dwell time batteryChargeStateDwell
Dwell (s) 30 0 300 10
  
Battery test
Enable batteryCapacityTestEnable
Enable no no yes n/a
  
Interval batteryCapacityTestPeriod
Interval (days) 183 7 730 1
  
Float time batteryCapacityTestDwell
Dwell (hrs) 10 1 120 1
  
Capacity batteryCapacityTestProportion
Test
proportion (%)
30 5 100 1
  
Duration
batteryCapacityTestDuration
Duration
(min)
30 10 900 5
  
End voltage
batteryCapacityTestThreshold
Threshold 47.5 40.0 55.0 0.1
  
d
p
i
Enable
batteryMidpointMonitorEnable
Enable no no yes n/a
  
