MAGNUM PRODUCT GUIDE CA013002EN—April 2017 www.eaton.com4
Overview of the Magnum low voltage circuit breaker
Eaton’s Magnum low voltage
power circuit breakers have
set industry standards for
decades for the global market.
The broad and powerful circuit
breaker offering provides
comprehensive solutions
to meet and/or exceed the
unique and wide-ranging
requirements of today’s power
distribution systems.
This innovative circuit breaker
offering is designed for
ultimate performance, custom
configuration, and application
flexibility. Magnum circuit
breakers combine many years
of successful circuit breaker
protection experience with the
latest technological advances
in circuit breaker, trip unit, and
communications performance.
Ever since introducing the first
microprocessor-based trip
unit, Eaton has advanced the
technology with its versatile
family of Digitrip RMS trip
units designed exclusively
for Magnum circuit breakers.
Customers have the capability
of providing an electrical
distribution system with:
•
Superior programmable
protection/coordination
•
Advanced warning
capabilities
•
System diagnostics/
monitoring/communications
Eaton’s Magnum family
address the needs of a
wide range of varying global
application requirements.
You will find product
details, dimensional
information, maintenance
recommendations, and
more when you take a
closer look within this
Magnum product guide.
Magnum consists of four
product families. Each
provides specific ratings,
features and approvals to
optimize performance in
concert with the application:
•
Magnum DS for ANSI rated
switchgear applications
•
Magnum SB for UL rated
switchboard applications
•
Magnum IEC for power
distribution and switchboard
applications
•
Magnum DC switches for
demanding UL or IEC rated
DC applications
Courtesy of NationalSwitchgear.com
