B-2
(PTO ENGAGE)
B-16
(PTO CONFIRM)
VBATT
(Fused)
B-15 (PTO REQUEST)
PTO
Engage
Relay
PTO Lamp/LED
B-14 (RTN_2)
CHASSIS GROUND
B-5 (RTN_1)
30
87
A
87
86
85
PTO 01
P
T
O
0
1
PTO
VBATT
SW02
SW04
SW03
SW01
DPST
PTO w/Confirm Switched to Chassis GND
Inside or on Dashboard
L+
L-
PTO-Power
PTO-Confirm
PTO-Ground
Contact Customer Support
Engineering for additional options
Switches shown in inactive posistion
PTO with Confirm Switched to Chassis
From To Description Notes
TCM - B-14 DPST - SW01 PTO Request
DPST - SW02 TCM - B-15 PTO Request
Vbatt
DPST - SW03 PTO Power Vbatt should be fused to pro-
tect wiring to PTO and PTO.
DPST - SW04 PTO Engage Relay - 30 PTO Engage
TCM - B-5 PTO Engage Relay - 86 PTO Engage
PTO Engage Relay -
85
TCM - B-2 PTO Engage
PTO Engage Relay -
87
PTO - PTO-Power PTO Engage
PTO - PTO-Ground Chassis GND PTO Ground
PTO - PTO-Confirm.
B-16
PTO Confirm Splice
PTO Lamp - L(-)
Vbatt
PTO Lamp - L(+) PTO Confirm Vbatt should be fused to pro-
tect Lamp circuit.
45
PTO Interface
