Chapter 3: Technical data/ratings
SC9000 EP medium voltage drives IB020001EN—February 2016 www.eaton.com 7
Table 2. Power specifications
Note
1
Contact factory.
Voltage class
2400
Drive rating (A)
69 80 91 103 114 134 156 178 201 223
2400 drive output (kVA)
287 333 378 428 474 557 648 740 836 927
Nominal hp 2400 V
300 350 400 450 500 600 700 800 900 1000
Frame size
Frame A Frame B
2400
Drive rating (A)
279 335 390 448 504 561
2400 drive output (kVA)
1160 1393 1621 1862 2095 2332
Nominal hp 2400 V
1250 1500 1750 2000 2250 2500
Frame size
Frame C Frame D
3300
Drive rating (A)
48 56 64 72 80 96 112 128 144 160 200 240 280 320
3300 drive output (kVA)
274 320 366 412 457 549 640 732 823 915 1143 1372 1600 1829
Nominal hp 3300 V
1
300 350 400 450 500 600 700 800 900 1000 1250 1500 1750 2000
Frame size
Frame A Frame B Frame C
3300
Drive rating (A)
360 400 440 480 520 560 600 640
3300 drive output (kVA)
2058 2286 2515 2744 2972 3201 3429 3658
Nominal hp 3300 V
1
2250 2500 2750 3000 3250 3500 3750 4000
Frame size
Frame D Frame E
4160
Drive rating (A)
38 44 51 57 63 76 89 101 114 124 140 155 186 217 248
4160 drive output (kVA)
274 317 367 411 454 548 641 728 821 893 1008 1117 1340 1564 1787
Nominal hp 4160 V
300 350 400 450 500 600 700 800 900 1000 1150 1250 1500 1750 2000
Frame size
Frame A Frame B
4160
Drive rating (A)
279 310 341 372 403 434 461 493 527 558 589 620 651 682 713 744
4160 drive output (kVA)
2010 2234 2457 2680 2903 3127 3321 3552 3797 4021 4244 4467 4690 4914 5137 5360
Nominal hp 4160 V
2250 2500 2750 3000 3250 3500 3750 4000 4250 4500 4750 5000 5250 5500 5750 6000
Frame size
Frame C Frame D Frame E
