Chapter 4: Handling, storage, and installation
SC9000 EP medium voltage drives IB020001EN—February 2016 www.eaton.com 11
Table 6. 4160 V AFD typical shipping section weights (lb)
Frame hp
Shipping sections
Converter TotalTransformer Inverter Main disconnect Incoming
A 300 5825 — — — — 5825
350 5925 — — — — 5925
400 6025 — — — — 6025
450 6225 — — — — 6225
500 6225 — — — — 6225
600 6525 — — — — 6525
700 6825 — — — — 6825
800 7175 — — — — 7175
900 7625 — — — — 7625
B 1000 6985 1940 — — — 8925
1250 7435 1940 — — — 9375
1500 8085 2040 — — — 10,125
1750 8585 2040 — — — 10,625
2000 9585 2340 — — — 12,025
C 2250 10,185 2540 1300 — — 14,025
2500 11,185 2540 1300 — — 15,025
D 3000 12,685 3040 1850 1300 — 18,325
3500 13,135 3740 1850 1300 — 19,575
4000 13,685 3840 1850 1300 — 20,125
4500 14,185 4040 1850 1300 — 20,825
5000 14,685 4140 1850 1300 — 21,425
E 4750–6000 18,300 4800 1850 1300 1300 27,550
