XS series operating manual
XS user manual v0.55 - 3 -
Restrictions due to the accessories or the
options
Ground continuity measurement
CO184/3 to CO184/10 : Maximum current regulation 10A for 6V, 20A for 12V.
CO183/3 to CO183/10 : Maximum current regulation 10A for 6V, 20A for 12V.
TE66/3 to TE66/10 : Maximum current regulation 10A for 6V, 20A for 12V.
TE80/3 to TE80/10 : Maximum current regulation 10A for 6V, 20A for 12V.
TE81/3 to TE81/10 : Maximum current regulation 10A for 6V, 20A for 12V.
CS1 : Maximum current regulation 10A for 6V, 20A for 12V.
Hipot test
CO193 CO174, CO185,CO192 : 4000VAC limited max. voltage.
CO200 to CO209 : 4000VAC limited max. voltage.
FMG501 : 4200VAC limited max. voltage.
Insulation measurement
CO 210 : Measurement limited to 2GΩ
FMG501 rack and Option MG-55 or MG-57(three phase) : Measurement limited to 2GΩ.
