25
**VT Thru–Drive Rear Mountings Installation Dimensions
**VT ThruĆDrive Rear Mountings
133,2
(5.25)
66,6
(2.62)
130,3
(5.13)
Ø
.375Ć18 UNCĆ2B
thd. 21,59 (.850)
thru flange 2 holes
(inch threads)
A"
To mounting flange
face
6,53
(.257)
1,45
(.057)
82,63
(3.25)
50,8
(2.00)
Ø
Ø
Snap ring
AS 568Ć230
OĆring req'd
L"
Output coupling
9T 16/32 DP Spline
Pump
Model
Dimension A"
Dimension
L"*
**VTAS Models **VTAM Models
25VTA 236,5 (9.3) 236,5 (9.3)
32,6/31,0
(1.28/1.22)
33,0 (1.30)
Maximum
35VTA 259,1 (10.2) 259,1 (10.2)
32,6/31,0
(1.28/1.22)
35,6 (1.40)
Maximum
45VTA 291,6 (11.5) 321,8 (12.7)
32,6/31,0
(1.28/1.22)
35,3 (1.39)
Maximum
* Caution: Dimension L" is important and must be observed.
A" Rear Mounting
NOTE: This unit accepts a hydraulic
pump which conforms to flange and
shaft codes specified in ISO 3019/1
(SAE J744 Jul88).
106,38
(4.188)
53,19
(2.094)
66,6
(2.62)
45°
**VTA
The following Vickers shaft selection
will comply with the above:
Rear Pump
Model
Shaft
V10 Vane pump 11
V20 Vane pump 62
PVB5/6 Piston pump S124
Flange
Code
Shaft
Code
SAE
J744C (Ref)
82Ć2 16Ć4 A
To Next Page
