Eaton Vickers V Series User Manual

7
Thru-Drive Pump Model Code
3 4 5 987 121 2 13
Model Code
1
2
F3 - Viton Seals
Omit if not required
Series Designation
25VT - 33 to 67 cm
3
/r (2.0 to 4.1 in
3
/r)
35VT - 81 to 121 cm
3
/r (4.9 to 7.4 in
3
/r)
45VT - 138 to 193 cm
3
/r
(8.4 to 11.8 in
3
/r)
Rear Pump Mounting
SAE (ISO 3019/1) 2-bolt
A - SAE “A”
B - SAE “B”
C - SAE “C” (35VT & 45VT only)
BP - SAE “B” to mount
PVE12/19/21 piston pump
Pilot Designation
M - Metric per ISO 3019/2 100A2HW
S - Standard pilot per ISO 3019/1
(SAE J744)
Geometric Displacement
(Rated capacity (USgpm) at 1200 rpm,
6,9 bar (100 psi)
Frame Code cm
3
/r in
3
/r
Size
(USgpm)
25VT 10 33 2.01
12 40 2.47
14 45 2.78
17 55 3.39
21 67 4.13
35VT 25 81 4.94
30 97 5.91
35 112 6.83
38 121 7.37
45VT 42 138 8.41
45 147 8.95
50 162 9.85
60 193 11.75
3
4
6
7
8
9
11
Port Connections
A - SAE 4-bolt flange
Port Connection Modifier
Omit - Inch thread port connection
(4-bolt flange)
M - Metric port connection
(4-bolt flange)
Thru-Drive Coupling
2 - Coupling with pump (included)
Pump Tail shaft pump
Series Requirements
**VTA SAE “A” size w/30 involute
spline, 9T 16/32 D.P.
**VTB SAE “B” size w/30 involute
spline, 13T 16/32 D.P.
**VTC SAE “C” size w/30 involute
spline, 14T 12/24 D.P.
Shaft
Outlet Postions
(Viewed from cover end of pump)
A - Opposite end
B - 90 CCW from inlet
C - Inline with inlet
D - 90 CW from inlet
Thru-Drive Adapter Orientation
(Viewed from cover end of pump)
SAE - A Adaptor
A - Rotate 45 CW with respect to
pump mounting flange
B - Rotate 45 CCW with respect to
pump mounting flange
SAE - B, BP or C adaptor
A - Inline with pump mounting flange
B - Rotate 90 with respect to pump
mounting flange
Design
Rotation
(Viewed form shaft end of pump)
L - Left hand for counterclockwise
R - Right hand for clockwise
Model
SAE Str.
Key
ISO Str.
Key
SAE
Spline
25VT
35VT
45VT
202
N/A
N/A
292N
292N
292N
297
297
297
203
203
203
11
HD Str.
Key
5
10
12
6 10
13
Note: For options other than listed in the model code, i.e. shafts, ports, displacements
and mountings, contact your Vickers representative.
