ASSEMBLING THE MOTOR TO THE PUMP - EVMSU1 to EVMSU20 [-A-]
360°
a
b
M6=15 Nm
M8=20 Nm
M12=40 Nm
M16=70 Nm
a
b
EVMSU
3/8”=19.7 lb-ft
1/2”=43 lb-ft
5/8”=92 lb-ft
