Setting
Printing ParameterS
Acve text : DATE The name of the acve/printed text.
Linked param. : The name of a parameter block linked with the acve text.
Height (pix) : 16 The height of the acve/printed text; it is given as a number of dots.
Matrix height : LARGE
A rough adjustment of print height by selecng one of the pre-
dened height sengs.
Print height : 100%
Recommended seng: 100%. A descripon of the parameter is
given in The BOLTMARK
®
II-series Printers User Manual.
Speed Level :
SLOW 29.2m/min
A speed level is selected for obtaining the opmum print quality
(SLOW) or the maximum traveling speed of the conveyor belt (FAST).
The parameter also gives the maximum traveling speed of the con-
veyor belt for a selected prinng algorithm.
For Generator = GEN, the a/m speed is the maximum value of
the Cnv spd m/min parameter.
Generator :
GEN 10.020 m/min
SHAFT 0.000 m/min
The source of ming signals: an internal generator or
a sha-encoder.
The parameter also gives the current conveyor belt travel speed.
For Generator = GEN, the a/m speed is close to the value of the
Cnv spd m/min parameter.
For Generator = SHAFT, the a/m speed equals conveyor belt travel
speed measured.
Resol. dot/cm :
20 (20.00) 0%
The seng of print resoluon in the horizontal direcon.
For Generator = SHAFT, except for the resoluon seng, also real
resoluon and the dierence between resoluon seng and real
resoluon [in %] are given.
Cnv spd m/min : 10.0
For Generator = GEN, conveyor belt travel speed is given.
The speed cannot be higher than the value given via the Speed
Level parameter.
Enc const p/m :
10000 (xx)
The real (and virtual) number of pulses transferred by the sha-en-
coder per unit of length.
To adjust prinng speed to conveyor belt travel speed (if Generator
= SHAFT).
Vert. direct. :
STANDARD
Vercal direcon of prinng: standard, diverted.
Space : 2.0 mm
Space between the beginning of an object and the beginning
of the print.
Space2 : ‑‑‑ Oponal parameter.
