20111028#4.2 EBS Ink-Jet Systeme
EN
33
EN
Parameter Description
Working pressure
from 0.03 MPa to 0.04 MPa
(from 0.3 bar to 0.4 bar)
Operating temperature range from +5°C to +40°C
Storage temperature range
(over a longer period)
from +1°C to +45°C, if water-based ink is
used for printing.
from -10°C to +45 °C if acetone or etha-
nol -based ink is used for printing.
Humidity
Up to 95% without steam condensa-
tion - at temperatures higher than the
dew point (the printer can be operated
when it rains provided that the surface to
be labelled is dry).
Weight
980±10 g
printer with a battery and full ink con-
tainer, without power pack and cable.
Dimensions in vertical position
(length / width / height)
240 / 130 / 265 mm
Dimensions in working position
See figure
H
below (provided that the
surface to be labelled is vertical).
