28
Identifier Name Description
A Operation mode
Select Rhythm, AUTO and Manual mode from the
keyboard
B Baseline drift filter
Select it in the filter setup interface, refer to Chapter
5.5.6
C EMG filter
Select it in the filter setup interface, refer to Chapter
5.5.6
D Time and date
Set it in the time and date setup interface, refer to
Chapter 5.5.7
E Power supply mode Indicate the current power supply mode, AC or battery
F Heart rate Current Heart rate value
G Name Patient name: no more than 20 characters
H ID Patient ID: no more than 10 digits
I
Leads and waveform
display
Display the waveforms
F1 Patient
Press【F1】,enter patient information setup interface
F2 Paper speed setup
Press 【 F2 】 ,choose paper speed within 6.25mm/s,
12.5mm/s,25mm/s,50 mm/s
F3 Sensitivity setup
Press【F3】,choose sensitivity within 2.5mm/mV. 5mm/
mV,10mm/ mV,20mm/mV
F4 Save
Press【F4】,save current patient test waveforms
F5 More
Press【F5】,enter the second page of the main interface
