ECGMAC EM-301 - Appendix C Specification; Technical Index

56
1.20 The range of voltage input
Each lead should no less than 0.03 to 5mV and the waveform should be correct.
1.21 Tolerance of Weighted parameters
Should be no more than ±10%。
1.22 Waveform identification and amplitude-time parameters measurement
Should match with the waveform shown in A.1,A.2 and A.3 in appendix JJG 1041-2008.
The testing result comply with the value range of A.1.1～A.1.4，A.2.1～A.2.2 in appendix
JJG 1041-2008.
1.23 Voltage measurement tolerance
Should not excess the value range of table A.1.1～A.1.4 in appendix JJG 1041-2008
1.23.1 Measurement tolerance of time interval
Should not excess the error range of table A.2.1, A.2.2 in Appendix JJG 1041-2008
Appendix C Specification
C.1 Technical Index
1) Main Machine
Lead Standard 12 Leads
Sampling Method 12 leads simultaneously
Measurement Parameter
HR, PR interval, QRS duration, QT/QTC, R/QRS/T electric
axis, RV5/SVI amplitude
Input Method Floating Ground input with defibrillator protection
Manual Mode (Manual 1 lead, Manual 2 Lead, Manual 3 Lead,
Manual 6 Lead)
Rhythm Mode
Recording Mode
Auto Mode （ 3CH × 4, 3CH × 4+1 rhythm, 3CH ×
4+3rhythm, 6CH×2, 6CH×2+1rhythm）
Filter
AC Filter: 50 Hz /60 Hz/ Off
EMG Filter: 30 Hz /40Hz/ Off
DFT Filter:0.05 Hz /0.15 Hz /0.25 Hz /0.5Hz/ Off
Input Circuit Current ≤0.1 μA
Input Impedance
≥50 MΩ（10 Hz）
