CLUTCH SYSTEM
CS-310
38
5 CLUTCH SYSTEM
( A ) Worm gear
( B ) Clutch plate
( C ) Clutch plate
( D ) Clutch spring
( E ) Clutch shoe
( F ) Clutch hub
( G ) Clutch assembly
( H ) Needle bearing
( J ) Clutch drum
( K ) Washer
( L ) E-Ring
(J)
(K)
(E)
(D)
(C)
(B)
(A)
(G)
(F)
(L)
(H)
