CHAIN BRAKE SYSTEM
CS-310
42
6 CHAIN BRAKE SYSTEM
( A ) Brake lever
( B ) Collar
( C ) Washer
( D ) Torsion spring
( E ) Spacer
( F ) Brake cover
( G ) Brake connector
( H ) Spacer
( J ) Spacer
( K ) Compression spring
( L ) Brake band
( M ) Roller
( N ) Engine cover
(G)
(E)
(F)
(D)
(C)
(A)
(H)
(K)
(J)
(N)
(B)
(L)
(M)
