OPERATION PAS-225 VP
30 X7732274200
© 5/2017 ECHO Inc.
Starting Warm Engine
The starting procedure is the same as Cold Start except DO NOT close the
choke, and do not hold throttle trigger fully depressed.
The attachment should not move at idle, otherwise serious per-
sonal injury may result.
Note: If attachment moves, readjust carburetor according to “Car-
buretor Adjustment” instructions in this manual or see your
ECHO Dealer.
1. Stop Switch
Move stop switch button (A) for-
ward away from the STOP posi-
tion.
2. Purge Bulb
Pump purge bulb (C) until fuel is
visible in the “Clear” fuel return
line. Pump bulb an additional 4
or 5 times.
3. Recoil Starter
Lay the unit on a flat area and
keep movable attachment parts
clear of all obstacles. Firmly grip
throttle handle and throttle trig-
ger lockout with left hand. Rap-
idly pull recoil starter handle/
rope (D) until engine fires.
Note: If engine does not start
after 5 pulls, use Cold Start Procedure.
A
C
D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Echo PAS-225 and is the answer not in the manual?

Echo PAS-225 Specifications

General IconGeneral
Engine Displacement21.2 cc
Engine Type2-stroke
Starting SystemRecoil
Shaft TypeStraight
Handle TypeLoop
Fuel Capacity14.9 fl. oz
Shaft Length59 inches
Warranty5 years consumer / 2 years commercial
Power Output0.7 kW
Dry Weight5.1 kg
