MAINTENANCE PAS-225 VP
36 X7732274200
© 5/2017 ECHO Inc.
3. Use brush to remove dirt from
the cylinder fins (C).
4. Remove ignition wires from clip
for cleaning.
5. Remove grass and leaves from
the grid (D) between the recoil
starter and fuel tank.
6. Assemble components in
reverse order.
Exhaust System
Spark Arrestor Screen
Level 2.
1. Remove spark plug lead and engine cover.
2. Place piston at Top Dead Center (TDC) to prevent carbon/dirt from
entering cylinder.
Parts Required: Spark Arrestor Screen, Gasket
C
D
D

Echo PAS-225 Specifications

General

Engine Displacement	21.2 cc
Engine Type	2-stroke
Starting System	Recoil
Shaft Type	Straight
Handle Type	Loop
Fuel Capacity	14.9 fl. oz
Shaft Length	59 inches
Warranty	5 years consumer / 2 years commercial
Power Output	0.7 kW
Dry Weight	5.1 kg
