Echo Power Pruner PPT-300ES - Guide Bar and Chain Lubrication; Automatic Oiling System; Automatic Oiler Adjustment; Oiler Volume Adjustment

Po w e r Pr u n e r
TM
oP e r a T o r 's Ma n u a l
17
1. Wipe debris from around oil ll cap.
2. Remove oil ll cap and ll reservoir with a quality, low viscosity
guide bar and saw chain oil.
IMPORTANT
To prevent plastic deterioration, do not use synthetic or silicone
based oil.
a d j u s t I n g a u t o m a t I c o I l e r
1. From bottom of gear case, turn adjustment screw (A) clockwise to
decrease oil volume - counter clockwise to increase oil volume.
NOTE
The automatic oiler is preset to deliver a sufcient oil discharge
volume during normal operating conditions. During heavy or dry
cutting conditions, the oil discharge volume may be increased to as-
sure adequate lubrication. If oil is leaking from the bar cover area,
reduce the oil discharge volume. Rell the oil reservoir with each
tank of fuel.
NOTE
Very little visible oil on the saw chain will provide sufcient lubri-
cation.
l u b r I c a t I n g t h e g u I d e b a r a n d s a w c h a I n
Automatic Oiling System
A
